AIMB-785 User Manual 16
2.4 VGA Connector and DVI-D Connector (DVI1/
DVI2 + VGA1)
The AIMB-785 includes both VGA and DVI-D interface that can drive conventional
CRT and LCD displays. Pin assignments of VGA1 and DVI1/DVI2 are detailed in
Appendix B.
2.5 Serial Ports (COM1, COM2, COM3, COM4, COM5
& COM6)
The AIMB-785 offers six serial ports (one on the rear panel and five onboard). RS-
232/422/485 mode is selected by BIOS for COM3. These ports can connect to a
serial mouse, printer or communications network. The IRQ and address ranges for
5
15
1
11
10 6
VGA1
DVI1
DVI2
VGA
DVI
COM1
COM1 COM2
COM3 COM4
COM5 COM6
VGA1+COM1
COM3
COM4
COM5
COM6
COM2
