1.1 Introduction
The ASMB-813I serverboard is the most advanced Intel
®
Xeon
®
E5-2600 v3 series
board for server-grade IPC applications that require high-performance computing
power & multi-expansion slots. This serverboard supports Intel Xeon E5-2600 v3
series processor and DDR4 2133/1866/1600 MHz memory up to 256 GB.
ASMB-813I provides five PCIe x16 slots (Gen3 x8 link) or two PCIe x16 slots (Gen3
x16 link)+ one PCIe x16 slots (Gen3.0 x8 link) and one PCie x8 slot (Gen2.0 x4 link)
+ one PCie x1 slot(Gne2 x1 link).
In addition, the ASMB-813I has dual Gigabit Ethernet LAN ports via a dedicated PCIe
x1 bus, which offer bandwidth up to 500 MB/s, eliminating network bottlenecks.
One RJ-45 LAN jack is shared with IPMI function that allows remote control manage-
ment. High reliability and outstanding performance makes ASMB-813I the ideal plat-
form for industrial server/networking applications.
By using the Intel C612 chipset, the ASMB-813I offers a variety of features such as 8
onboard SATA III interfaces; it supports IRST (Intel Rapid Storage Technology) and
provides RAID 0, 1, 10 and 5 (Windows only*); and it has 6 USB 3.0 and 5 USB 2.0
connectors.
These powerful I/O capabilities ensure even more reliable data storage capabilities
and high-speed I/O peripheral connectivity.
1.2 Features
General
 Intel
®
E5-2600 v3 processor support: ASMB-813I supports Intel E5-2600 v3
series six/eight/ten/twelve/fourteen/sixteen/eighteen core processors.
 High performance I/O capability: Dual Gigabit LAN, 5 x PCIe x16 slot (x8 link) +
1 x PCIe x8 slot (x4 link) + 1x PCIe x1 slot (x1 link), 8 x SATA connectors and 6
x USB 3.0, 5 x USB 2.0.
 Standard ATX form factor with industrial features: ASMB-813I provides indus-
trial features like long product lifecycle, reliable operation under wide tempera-
ture range, watchdog timer, etc.
 IPMI 2.0 support: ASMB-813I equipped with ASPEED 2400 BMC chip supports
IPMI 2.0 (Intelligent Platform Management Interface 2.0) via sharing LAN port.
 KVM over IP: ASMB-813I KVM over IP function allows remote control of system
through your own computer.
Note! 1. IPMI module will be included in ASMB-813I sku.
2. Five USB 2.0 ports (1*Type- A) and six USB 3.0 ports (2 ports from
on-board 20-pin header)
3. Please refer to the release note of each Linux OS for Intel's C612
chipset SATA RAID function support.
