85 ASMB-813I User Manual

Appendix B I/O Pin Assignments

B.8 External Speaker Connector (JFP2)

B.9 Reset Connector (JFP1)

B.10 HDD LED Connector (JFP1)

Table B.8: External Speaker Connector (JFP2)

Pin Function

1 SPK+

4NC

7BZ-

10 SPK-

1 4 7 10

Table B.9: Reset Connector (JFP1)

Pin Signal

9 RESET

12 GND

9 12

Table B.10: HDD LED Connector (JFP1)

Pin Signal

5 HDD_LED+

7 HDD_LED-

2 5
