ASMB-813I User Manual 86
B.11 ATX Soft Power Switch (JFP1)
B.12 Front panel SMBus Connector (SMBUS1)
Table B.11: ATX Soft Power Switch (JFP1)
Pin Signal
1PWR-BTN
3GND
3 6
1 +3.3V_AUX
2 SMB_SCL_FRU
3 SMB_SDA_FRU
4GND
