Advantech ASMB-813I User Manual

3 ASMB-813I User Manual
Chapter 1 Overview
1.3 Specifications
Table 1.1: Specifications
Processor
CPU
 Intel
®
LGA2011 Xeon processor sockets
 Supports Intel
®
Xeon
®
E5-2600 v3 series processor with six/
eight/ten/twelve/fourteen/sixteen/eighteen cores
 Supports the TDP of processor up to 160 W
System Memory
Memory Capacity
 Xeon
®
processor supports DDR4 memory bus
 Total 8 memory slots provided
 Supports up to 256 GB memory
 Quad channels per processor, 2 memory slot per channel
Memory Type Supports DDR4 2133/1866/1600/1333 MHz ECC-REG Modules
DIMM Sizes Each memory slot supports 1GB, 2GB, 4GB, 8GB, 16GB and
32GB memory modules
Memory Voltage 1.2V
Error Detection  Corrects single-bit errors
 Detects double-bit errors (using ECC memory)
On-Board Devices
Chipsets
Intel
®
C612 PCH provide 8xPCIe Gen2 lanes
Network Controllers  2 x Intel I210 Gigabit Ethernet Controller connected to C612
through PCIe x1 Gen2 Lane
 Above network supports 10BASE-T, 100BASE-TX, and
1000BASE-T, with RJ-45 output
VGA ASPEED AST2400/1400 controller with 64 MB VGA memory pro-
vides basic 2D VGA function.
Super I/O Nuvoton NCT6776D chip provide motherboard keyboard mouse,
RS-232, parallel port and hardware monitor functions
BMC (813I SKU Only) One of Intel I210 Gigabit Ethernet connected to AST2400 for shar-
ing IPMI / IKVM.
Input / Output
Serial ATA  Total 8 x SATA ports and provide 6 Gb/s bandwidth
 RAID 0, 1, 5, 10 support (Windows only. For Linux support
please refer to the note item 3 of chapter 1.1)
LAN  2 x RJ-45 LAN ports (10/100/1000 Base-T LAN)
USB  4 x USB 3.0 ports at rear window
 2 x USB 2.0 ports at rear windows
 1 x USB 2.0 internal headers (2 ports)
 1 x USB 3.0 internal header (2 ports)
 1 x internal Type-A USB port.
VGA  1 x VGA port
Keyboard / Mouse  PS/2 keyboard and mouse connector (onboard).
Serial Port / Header  1 x internal header (2 x 5P pitch: 2.50 mm)
Power Connector
System Power 1 x 24-pin SSI EPS 12 V power connector (Input 12 V, 5 V, 3.3 V, 5
V standby)
CPU Power 2 x 8 pin SSI EPS 12 V power connector for CPU & Memory power
(12V)
