7 ASMB-813I User Manual
Chapter 1 Overview
HDAUD1 Audio header
JCASE1 Chassis case open alarm header
JFP1/JFP2/JFP3 Front panel pin header connector
KBMS2 For additional keyboard/mouse
LAN1, LAN2 RJ-45 LAN connector
LANLED1 LAN1 & LAN2 LED extension connector
LPC1 LPC port for debug & TPM module
PMBUS1 Power supply SMBbus I2C Header
SATA0~SATA43
SATA0~SATA3
Serial ATA0~3, Slave serial ATA0~3
SGPIO1, SGPIO2 Supports Serial_Link interface for onboard SATA connections
SLOT1 PCIE x1 slot of PCH
SLOT2 PCIE x16 slot
SLOT3 PCIE x16 slot
SLOT4 PCIE x16 slot
SLOT5 PCIE x16 slot
SLOT6 PCIE x16 slot
SLOT7 PCIE x8 slot of PCH
SMBUS1 SMBus header (For Advantech chassis usage)
SPI_CN1 Connector for BIOS update tool
SYS FAN0 System fan connector (4-pin)
SYS FAN1 System fan connector (4-pin)
SYS FAN2 System fan connector (4-pin)
SYS_LED1 System LED connector USB0_1, USB2_3,
USB6_7 USB 3.0 port 0, 1, 2, 3; USB 3.0 port 6, 7 (20pin header)
USB45,USB89 USB 2.0 port 4,5,8,9
USB10 USB 2.0 port 10 (Type-A)
VGA1 VGA connector
VOLT1 For Advantech alarm board usage
JPRSNT 1/2 Manual switch PCIE slot 3/4 or slot 5/6 to PCIE x8 link
Table 1.5: Onboard LED
LED Description LED Definition
5V_LED1 Power on LED Off:
Power off
On (Green):
System is On
5VSB_LED1 Standby LED Off:
No input AC Power
On (Green):
System is ON, in sleep mode,
or in soft-off mode
LED3 BMC heartbeat LED
(820I SKU Only)
Blinking (Green):
Controller is working normally
Table 1.4: Connectors
