ASMB-813I User Manual 26
2.17 PMBUS Connector (PMBUS1)
2 RTC_RST_PCH HDA_SDOUT_PCH
3 GND 3.3V
1SMB_SCL_PM
2 SMB_SDA_PM
3 SMB_ALT_PM
4GND
5+3.3V
PMBUS1
