ASMB-813I User Manual 82

B.1 USB Header (USB89)

B.2 USB3.0 Header(USB6_7)

Table B.1: USB Header (USB89)

Pin Signal Pin Signal

1 USB_VCC5 2 USB_VCC5

3 USB_D- 4 USB_D-

5 USB_D+ 6 USB_D+

7 GND 8 GND

9 Key 10 N/C

USB89

Table B.2: USB Header (USB67)

Pin Signal Pin Signal

1 +5 V 2 STDA_SSRX-

3 STDA_SSRX+ 4 GND

5 STDA_SSRX- 6 STDA_SSRX+

7GND 8D-

9D+ 10OC#

11 D+ 12 D-

13 GND 14 STDA_SSRX+

15 STDA_SSRX- 16 GND

17 STDA_SSRX+ 18 STDA_SSRX-

19 +5 V 20

10 2 1

11 19

Advantech ASMB-813I User Manual
