21 ASMB-813I User Manual

Chapter 2 Connections

2.8.6 Case Open (JCASE1)

SNMP connector could connect with “SAB-2000” remote control board to monitor

ASMB-813I through the super IO chip.

2.9 SATA SGPIO (SGPIO1 & 2)

JCASE1

1SCLOCK_PCH

2NC

3SLOAD_PCH

4SDATAOUT0_PCH

5SDATAOUT1_PCH

SGPIO1

SGPIO2
