5 ASMB-813I User Manual
Chapter 1 Overview
1.4 Board Layout, Jumpers and Connectors
Connectors on the ASMB-813I are linked to external devices such as hard disk
drives. In addition, ASMB-813I has a number of jumpers that are used to configure
the system for specific applications.
The tables below list the functions of each jumper and connector. Later sections in
this chapter give instructions for setting jumpers. Chapter 2 gives instructions for con-
necting external devices to ASMB-813I.
Figure 1.1 Board Layout
Figure 1.2 Rear I/O
