Peripheral Compatibility
Initial Inspection
Before installing motherboard, please make sure that the following
materials have been shipped:
 1 x ASMB-813I ATX motherboard
 1 x ASMB-813I Startup Manual
 1 x Driver CD (user manual is included)
 2 x Serial ATA HDD data cables
 1 x I/O port bracket
 2 x CPU power cable (8P)
 2 x SATA power cable
 1 x Warranty card
If any of these items are missing or damaged, contact distributor or sales representa-
tive immediately. We have carefully inspected the ASMB-813I mechanically and elec-
trically before shipment. It should be free of marks and scratches and in perfect
working order upon receipt. When unpacking the ASMB-813I, check it for signs of
shipping damage. (For example, damaged box, scratches, dents, etc.) If it is dam-
aged or it fails to meet the specifications, notify our service department or local sales
representative immediately. Also notify the carrier. Retain the shipping carton and
packing material for inspection by the carrier. After inspection, we will make arrange-
ments to repair or replace the unit.
Category Advantech PN Vendor Part Description Remarks
MB
ASMB-813I-00A1E Advantech Support BMC module
ASMB-813-00A1E Advantech Basic sku
CPU
Intel
®
E5-2600 v3 product family (DQA QVL CPUs)
96MPXE-1.9-15M20T
Intel
®
XEON
®
1.9G 15M 2011P 6CORE E5-2609V3
96MPXE-2.2-30M20T
Intel
®
XEON
®
2.2G 30M 2011P 12CORE E5-2658V3
96MPXE-2.4-15M20T
Intel
®
XEON
®
2.4G 15M 2011P 6CORE E5-2620V3
96MPXE-2.5-30M20T
Intel
®
XEON
®
2.6G 20M 2011P 8CORE E5-2640V3
96MPXE-2.5-30M20T
Intel
®
XEON
®
2.5G 30M 2011P 12CORE E5-2680V3
SATA3
HDD
2.5" & 3.5" SATA2 & SATA3 HDD device (DQA QVL
HDDs)
Memory
DDR4 ECC-REG 2133/1866/1600 MHz DIMM
(DQA QVL DIMM modules)
AQD-D4U4GR21-HG Advantech 4G R-DDR4-2133 1.2V 512X8 HYX
AQD-D4U8GR21-HZ Advantech 8G R-DDR4-2133 1.2V 512X8 HYX
AQD-D4U16R21-HZ Advantech 16G R-DDR4-2133 1.2V 512X8 HYX
AQD-D4U4GR21-SG Advantech 4G R-DDR4-2133 1.2V 512X8 SAM
AQD-D4U8GR21-SG Advantech 8G R-DDR4-2133 1.2V 512X8 SAM
Cooler/
Heatsink
1960063011N001 CoolJag
LGA-2011 narrow CPU cooler for 2U/ 4U chassis (145
W)
1960058073N001 CoolJag
LGA-2011 narrow CPU cooler for 2U/4U chassis (95
W)
Option
Card
PCA-AUDIO-HDA1E Advantech Audio card
Riser
Card
ASMB-RF348-21A1E Advantech ASMB-RF348 (2U riser card)
2*PCI-E x4 +
1*PCI-E x8
ASMB-RF3X8-21A1E Advantech ASMB-RF3X8 (2U riser card)
1*PCI-Ex4 +
2*PCI-X

Advantech ASMB-813I Specifications

General

Brand	Advantech
Model	ASMB-813I
Category	Server Board
Language	English
