Advantech ASMB-813I User Manual

ASMB-813I User Manual 50
Note! 1. Intel® recommends exposing all 3 snoop modes as BIOS options
to the user due to the varying memory latency & bandwidth trade
offs across SKUs for each snoop mode.
a). Intel® Xeon® Processor E5-2600 v3 Product Family supports
up to 3 different snoop modes (Early Snoop, Home Snoop, Cluster
on Die) to maintain memory coherency across the 2 sockets.
b). Choosing the optimal snoop mode setting is dependent on the
workload characteristics and the SKU that is used.
2. It is expected behavior for LCC SKUs (4-8 cores) in NUMA & Early
Snoop mode to have low remote bandwidth.
a). For workloads on LCC SKUs that need high local & remote
memory bandwidth, use NUMA & Home Snoop mode at the
expense of higher memory latency (up to 1.07x).
b). For workloads on LCC SKUs that have mostly remote memory
accesses, use UMA & either Early Snoop or Home Snoop mode.
Snoop Mode Configuration Cluster on Die Enable Early Snoop Mode
Early Snoop (ES) Disable Enable
Auto Auto
Auto Enable
Disable Auto
Home Snoop (HS) Disable Disable
Auto Disable
Cluster on Die (COD) Enable Disable
Enable Auto
Not Supported - Invalid Settings Enable Enable
