5 EKI-1500 Series User Manual
2.2 DE Version Specifications
Software Driver Support 32-bit/64-bit Windows XP/Vista/7/8/8.1/10, Windows
Server 2003/2008/2008 R2/2012/2012 R2, and Linux
Utility Advantech EKI Device Configuration Utility
Operation Modes
COM port redirection mode (Virtual COM)
TCP/UDP server (polling) mode
TCP/UDP client (event handling) mode
Pair connection (peer to peer) mode
Configuration Windows utility, Telnet console, Web Browser
Management SNMP MIB-II
Regulatory
Approvals
EMC CE, FCC Part 15 Subpart B (Class A)
Specifications Description
Specifications Description
Interface I/O Port
EKI-1521CI-DE: 2 x RJ45 + 1 x RS-232/422/
485-2w/485-4w
EKI-1522CI-DE: 2 x RJ45 + 2 x RS-232/422/
485-2w/485-4w
Serial
Communications
Port Connector DB9 male; Terminal block
Protection Built-in 15 KV ESD for all signals
'CI' models: 2KV Isolation for RS-232/422/485 signals
