EKI-1500 Series User Manual 12
The following view shows the EKI-1524.
Figure 2.7 Rear View
2.3.3 Top View
The following view is valid for the EKI-1521 and EKI-1522.
Figure 2.8 Top View
No. Item Description
1 DIN-Rail mounting
plate
Mounting plate used for the installation to a standard DIN rail
1
No. Item Description
1 Terminal block Connect cabling for power and alarm wiring
2 Ground terminal Screw terminal used to ground chassis
3 Wall mounting holes Screw holes (x4) used in the installation of a wall mounting plate
PWR2
P-Fail
DC12-48V
PWR1
V2- V2+ V1- V1+
1A@24V
1
3
2
