47 EKI-1500 Series User Manual
5. Locate From System Port and click the drop-down menu to select the target
COM port.
6. From the network address list, select the address options to map.
The selected address displays the Device Port and (EKI-1500 Series device
server physical serial port) and the system port which will be the VCOM port for
the PC.
Figure 5.2 Selecting Auto Mapping
7. From the network address list, select the address options to map.
8. Click Map Selected Ports to set the configuration.
Figure 5.3 Mapping Selected Ports
Once the mapping function is initialized, a successful mapping process results in the
virtual mapping of the designated physical serial port and VCOM PC port. See the
following figure.
Figure 5.4 Viewing VCOM Mapping Results
System Port
Device PortSelected Options
