Advantech EKI-1528-DR - COM Port Redirector (Virtual COM Port); Figure 4.1 Virtual COM Mode; Overview

EKI-1500 Series User Manual 38
4.1 Overview
The EKI-1500 Series is designed to network-enable any RS-232/422/485 serial
device, an provides industry-grade hardware and easy-to-use software to make con-
necting serial devices to an Ethernet network a surprisingly simple process.
These units immediately upgrade your existing serial devices for integration into the
Internet world. The EKI-1500 Series features many powerful functions, such as high
speed data transfer, access-control, auto-detection of all EKI-1500 Series products,
and more.
After the simple installation steps to attach your network and serial device to the
appropriate connectors on the serial device servers and driver installation, you will be
able to communicate with the serial devices via its own application software and wit
the EKI-1500 Series device server. COM port redirector, USDG TCP server mode,
TCP client mode, UDP server mode, UDP client mode, RFC2217 mode are all differ-
ent methods of making a serial connection across using one or more serial device
servers.
4.2 COM Port Redirector (Virtual COM Port)
Advantech EKI Device Configuration Utilityis a serial COM port redirector that cre-
ates virtual COM ports and provides access to serial device connected to Advantech
serial device server. You can configure the serial device server and enable the Virtual
COM port using one integrated utility. Advantech EKI Device Configuration Utilityal-
lows you to configure Microsoft applications to communicate with network enabled
serial device servers as easily as if they were physically installed in or directly con-
nected on the PC.
The Advantech redirector can create up to 255 virtual COM ports. Application to the
host can open a virtual COM port to access the serial device servers at the same
time. The redirector will handle each active virtual COM port as a separate TCP con-
nection to Advantech serial device servers.
Figure 4.1 Virtual COM Mode
