EKI-1500 Series User Manual 6
2.3 Hardware
2.3.1 Front View
The following view shows the EKI-1521.
Figure 2.1 Front View
No. Item Description
1 System LED panel See “LED Indicators” on page 13 for further details.
2 ETH port RJ45 ports x 2
3 Serial port DB9 pinout, supports RS-232/422/485
1
1
2
Default
LAN
TxRx
P1 P2 Status
Serial ports
EKI-1521
1
2
3
