Advantech EKI-1528-DR - Event; Figure 6.11 Alarm > Event

EKI-1500 Series User Manual 66
6.7.2 Event
The Alarm Event page allows the selection of triggers for system, DCD and DSR
events for the alarm function.
To access this page, click Alarm > Event.
Figure 6.11 Alarm > Event
The following table describes the items in the previous figure.
Item Description
System Event
Cold Start Click the option to select a warning type when the device server’s
power is cut off and reconnected.
Warm Start Click the option to select a warning type when the device server is
reboot.
Authentication failure Click the option to select a warning type when an incorrect pass-
word is entered.
IP address changed Click the option to select a warning type when the IP address is
changed.
Password changed Click the option to select a warning type when the password is
changed.
