EKI-1500 Series User Manual 28
3.3.2 Network Settings
Prior to setting up the server’s IP address determine the IP address mode.
There are four mode types available:
 Static IP: mode to assign a specific assigned address
 DHCP / AutoIP: mode to automatically assign IP addresses through a DHCP
server
 BOOTP / AutoIP: mode to automatically assign an IP address through the con-
figuration server
 DHCP/BOOTP/AutoIP: mode to automatically assign an IP address using a
Bootstrap Protocol or DHCP server.
The server is set with the following default IP configuration:
 10.0.0.1 (Eth1)
 10.0.0.2 (Eth2)
The EKI-1500 Series includes a software utility option, which you can install on your
system, for configuration through computer-based software. The EKI-1500 Series
also includes a web interface option for configuration through a standard web
browser.
Figure 3.10 Utility Overview
