13
IHBI. 1011. 4138500_00
Indoor units
Model External view Internal view
• HBI080C
• HBI100C
• HBI120C
• HBI140C
• HBI160C
7. MAIN COMPONENTS
Control box
Compressor
DC fan motor
Control box
Compressor
DC fan motor
Indoor units
Model External view Internal view
• HBI080E
• HBI100E
• HBI120E
• HBI140E
• HBI160E
Air vent
Electrical heater
Safety valve
Plate heat ex-
changer.
Control box
Control panel
Expansion vessel
Water pump
Flow switch
the image is purely indicative
the image is purely indicative
