ACCEPTANCE TESTING
5-39
Results table 5-6 Carrier harmonic test points at 0 dBm
Frequency
(MHz)
Second
harmonic
(MHz)
Result Third
harmonic
(MHz)
Result Upper
limit
(dBc)
0.4 0.8 _______ 1.2 _______
−20
100.0 200.0 _______ 300.0 _______
−20
300.0 600.0 _______ 900.0 _______
−20
500.0 1000.0 _______ 1500.0 _______
−20
700.0 1400.0 _______ 2100.0 _______
−20
900.0 1800.0 _______ 2700.0 _______
−20
1000.0 2000.0 _______ 3000.0 _______
−20
Results table 5-7 Spurious signals (carrier at 0 dBm)
Carrier
frequency
(MHz)
Spurious
measured
Upper
limit (dBc)
0.4 _______
−40
500 _______
−40
1000 _______
−40
650 _______
−30
Results table 5-8 RF carrier leakage (carrier at 501.9873 MHz)
Carrier
frequency
(MHz)
Upper
limit
Leakage
detected
501.9873
0.5 µV PD
_______
Results table 5-9 Residual FM test points
UUT
RF generator
frequency (MHz)
Local oscillator
frequency
(MHz)
Limits
(Hz)
Result
1000 55.63889 20 _______
400 50.18750 15 _______
100 50.75000 15 _______
