ACCEPTANCE TESTING
5-40
Results table 5-10 AM versus carrier frequency (50% depth at 1 kHz rate)
Carrier
frequency (MHz)
Lower
limit (%)
Upper
limit (%)
Result (%)
1.5 45.5 54.5 _______
50 45.5 54.5 _______
100 45.5 54.5 _______
150 45.5 54.5 _______
200 45.5 54.5 _______
250 45.5 54.5 _______
300 45.5 54.5 _______
350 45.5 54.5 _______
400 45.5 54.5 _______
Results table 5-11 AM versus carrier level (100 MHz, 70% depth at 1 kHz rate)
Carrier
level (dBm)
Lower
limit (%)
Upper
limit (%)
Result (%)
5 64.1 75.9 _______
4 64.1 75.9 _______
3 64.1 75.9 _______
2 64.1 75.9 _______
1 64.1 75.9 _______
0 64.1 75.9 _______
−1
64.1 75.9 _______
−2
64.1 75.9 _______
−3
64.1 75.9 _______
−4
64.1 75.9 _______
−5
64.1 75.9 _______
−6
64.1 75.9 _______
−7
64.1 75.9 _______
−8
64.1 75.9 _______
−9
64.1 75.9 _______
−10
64.1 75.9 _______
−11
64.1 75.9 _______
−12
64.1 75.9 _______
−13
64.1 75.9 _______
−14
64.1 75.9 _______
−15
64.1 75.9 _______
