ACCEPTANCE TESTING
5-41
Results table 5-12 AM linearity (100 MHz, 0 dBm at 1 kHz rate)
Am depth
set (%)
Lower
limit (%)
Upper
limit (%)
Result (%)
5 3.65 6.35 _______
10 8.3 11.7 _______
20 17.6 22.4 _______
30 26.9 33.1 _______
40 36.2 43.8 _______
50 45.5 54.5 _______
60 54.8 65.2 _______
70 64.1 75.9 _______
85 79.1 91.95 _______
Results table 5-13 AM versus modulation frequency (100 MHz, 85% depth)
AM frequency
(kHz)
Lower
limit (%)
Upper
limit (%)
Result (%)
0.065 75.5 94.5 _______
0.140 75.5 94.5 _______
0.500 75.5 94.5 _______
2 75.5 94.5 _______
5 75.5 94.5 _______
15 71.25 98.75 _______
Results table 5-14 AM demodulation distortion (100 MHz, 30% depth)
Distortion
upper limit (%)
Result (%)
2 _______
