Note: Climate conditions for transport are in accordance with
EN60721-3-2-class 2K4.
Temperature Between -40°C and 70°C (transport)
Relative humidity not combined with
rapid temperature changes
95% at +45°C
Total acoustic A-weighted noise power (method of measurement in ac-
cordance with ISO 3746:1995)
During operation 67 dB (=6.7B)
During stand-by 57 dB (=5.7B)
Film throughput
14x17” > 100/h
Access time
1 film 14x17” Max. 90 sec.
4 films 14x17” Max. 200 sec.
Print technology
Direct thermal printing
Reliability
Estimated product life
(if regularly serviced and maintained
according to Agfa instructions)
> 5 years and > 150,000 films
Service interventions Max. 2 interventions / 3 years
Earthquake (standard) Meets the CA requirements
Imaging Array - Diagnostic area - General radiography
8x10” 8” dimensions 10” dimensions
pixels mm pixels mm
3852 192,6 4880 244
10x12” 10” dimensions 12” dimensions
Drystar 5500, Drystar 5503 | Drystar 5500, Drystar 5503 | 15
2901J EN 20191018 0826
