Agilent 33500 Series Function / Arbitrary Waveform Generator
4
6
OUTPUT CHARACTERISTICS
ISOLATION
Outputs
Connector shells for Ch 1, Ch2 , Sync, and Mod In
are connected together but isolated from the
instrument's chassis. Maximum allowable voltage
on isolated connector shells is ±42 Vpk.
SIGNAL OUTPUT
Output
Impedance
(nom)
50 Ω
On, Off,
Inverted
User-selectable for each channel
Voltage Limit User-definable V
MAX
and V
MIN
safety limits
Overload
Protection
Output turns off automatically
when an overload is applied.
Instrument will tolerate a short
circuit to ground indefinitely.
FREQUENCY ACCURACY
STANDARD (spec)
1 Year
23°C ± 5 °C
±1 ppm of setting ± 15 pHz
1 Year
0°C to 55°C
±2 ppm of setting ± 15 pHz
OPTION 010 (spec)
1 Year
0°C to 55°C
±0.1 ppm of setting ± 15 pHz
