Chapter 6 Specifications
Agilent 33500 Series Function / Arbitrary Waveform Generator
4
6
Note: Specifications are subject to change without
notice. For the latest specifications, go to the Agi-
lent 33521A or Agilent 33522A product page for
the latest datasheet.
www.agilent.com/find/33521A
www.agilent.com/find/33522A
MEMORY
ARBITRARY WAVEFORM MEMORY
Volatile 1M samples / ch
512 Sequence steps / ch
Optional 16M point / ch
Non-Volatile File system file space is limited to
64 MB (approximately 32 MSa of
arbitrary waveform records).
INSTRUMENT STATE
Store / Recall User defined instrument states
Power Off Power Off state automatically
saved
Power On Selectable Reset, Power Off, or
User State
USB File System
Front-panel port USB 2.0 high-speed mass storage
(MSC) class device
Capability Read or Write instrument
configuration settings, instrument
states, and User Arbitrary
waveform and sequence files.
Speed 10 MB/s (nominal)
GENERAL CHARACTERISTICS
COMPUTER INTERFACES
LXI-C (rev 1.3) 10/100Base-T Ethernet (Sockets
& VXI-11 protocol)
USB 2.0 (USB-TBC488 protocol)
GPIB/IEEE-488.1, IEEE-488.2
Web User
Interface
Remote operation and monitoring
Programming
Language
SCPI-1999, IEEE-488.2
Agilent 33210A / 33220A
compatible
Graphical
Display
4.3” Color TFT WQVGA
(480x272) with LED backlight
MECHANICAL
Size 261.1mm W x 103.8mm H x
303.2mm D (with bumpers
installed)
212.8mm W x 88.3mm H x
272.3mm D (with bumpers
removed)
2U x 1/2-width
Weight 33521A: 3.2 kg (7.1 lbs.)
33522A: 3.3 kg (7.2 lbs.)
ENVIRONMENTAL
Storage
Temperature
-40˚ C to 70˚C
Warm-Up Time 1 hour
Operating
Environment
EN61010, Pollution Degree 2;
Indoor Locations
Operating
Temperature
0 ˚C to 55 ˚C
Operating
Humidity
5% to 80% RH, non-condensing
Operating
Altitude
up to 3000 meters
REGULATORY
Safety CAT II (300V), EN61010
EMC EN55011, EN50082-1, MIL-461C
Vibration &
Shock
MIL-T-28800, Type III, Class 5
Acoustic Noise 35 dB(A)
LINE POWER
Voltage 100 V - 240 V 50/60 Hz -5%,
+10%
100 V - 120 V 400 Hz ± 10%
Power
Consumption
(typ)
< 45 W, < 130 VA
WARRANTY
1 year standard, 3 years optional
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme NMB-001
du Canada.
