42
2
Front-Panel Menu Operation
This chapter introduces you to the front-panel keys and menu operation.
This chapter does not give a detailed description of every front-panel key
or menu operation. It does, however, give you an overview of the front-
panel menus and many front-panel operations. See chapter 3 “Features
and Functions,” starting on page 89, for a complete discussion of the
waveform generator’s capabilities and operation.
• Front-Panel Menu Reference, on page 43
• To Select the Output Termination, on page 47
• To Reset the Waveform Generator, on page 48
• To Output a Modulated Waveform, on page 49
• To Output an FSK Waveform, on page 51
• To Output a PWM Waveform, on page 53
• To Output a Frequency Sweep, on page 56
• To Output a Burst Waveform, on page 59
• To Trigger a Sweep or Burst, on page 62
• To Store the Instrument State, on page 63
• To Configure the Remote Interface, on page 65
• To Set up an Arbitrary Waveform, on page 73
