Installing the 86100C
Installation
W A R N I N G This is a Safety Class 1 Product (provided with a protective earthing ground
incorporated in the power cord). The mains plug shall only be inserted in a socket
outlet provided with a protective earth contact. Any interruption of the protective
conductor inside or outside of the product is likely to make the product dangerous.
Intentional interruption is prohibited.
CAUTION VENTILATION REQUIREMENTS: When installing the product in a cabinet, the convection into
and out of the product must not be restricted. The ambient temperature (outside the cabinet)
must be less than the maximum operating temperature of the product by 4° C for every 100
watts dissipated in the cabinet. If the total power dissipated in the cabinet is greater than
800 watts, then forced convection must be used.
CAUTION This product is designed for use in INSTALLATION CATEGORY II and POLLUTION DEGREE 2 per
IEC 1010 and 664 respectively.
Installation Category: Installation Categories (overvoltage categories) are
determined by the transient overvoltage levels that may be expected. CAT I:
Mains isolated. CAT II: Line voltage in appliance and to wall outlet. CAT III:
Line voltage behind wall outlet to next level of distribution.
NOTE Install the instrument according to the enclosure protection provided. This
instrument does not protect against the ingress of water. This instrument pro-
tects against finger access to hazardous parts within the enclosure.
