8-4 Option 100 Fault Location and SRL
Key Reference
Alphabetical Key Reference
Softkey in add limit menu. Displays menu to add a minimum limit
line.
See “Using Limit Lines” in Chapter 4 of your analyzer's User's Guide
for detailed information on using limit lines.
Access Keys:
Softkey in add limit menu. Displays menu to add a minimum limit
point.
See “Using Limit Lines” in Chapter 4 of your analyzer's User's Guide
for detailed information on using limit lines.
Access Keys:
Softkey in the menu that turns off all of the markers, the
delta marker, and marker tracking on the active measurement
channel.
See “Using Markers” in Chapter 4 of your analyzer's User's Guide for
detailed information on using markers.
Softkey in the connector model menu. This softkey is used to toggle
the SRL measurement automatic impedance function on or off. The
analyzer can either automatically compute the impedance on each
sweep (auto Z = ON), or use a value that you have entered
(auto Z = OFF).
The value of Z is displayed at the top of the measurement display.
(See Figure 4-9 on page 4-18.)
Access Keys:
or
(You must already be
in SRL measurement mode to access the connector
model menu via the key.)
Softkey in menu. Scales the data trace vertically to fit
within the graticule area of the display.
DISPLAY
DISPLAY
MARKER
BEGIN
CAL
CAL
SCALE
