Agilent Technologies 8712ET User Manual

8-18 Option 100 Fault Location and SRL
Key Reference
Alphabetical Key Reference
Softkey in the fault location and fault loc frequency menus.
Access Keys:
or
Softkey in the connector model menu. Allows you to enter a fixed
value for Z when making SRL measurements. Auto Z must be turned
OFF before you can enter a value using .
Access Keys:
or
(You must already be
in SRL measurement mode to access the connector
model menu via the key.)
Softkey in add max line, add min line, add max point, and add min
point menus. Adds a marker to the data trace and allows it to be
moved to identify trace frequencies and amplitudes.
Access Keys:
// /
Hardkey in the CONFIGURE area. Displays menu to set markers,
use marker search and delta markers.
See “Using Markers” in Chapter 4 of your analyzer's User's Guide for
more information.
Softkey in menu. Invokes menu to select delta marker
mode, marker to center, marker to reference, and marker to electrical
delay.
Low Pass
BEGIN
Cable
Fault Location
FREQ
Fault Loc Frequency
Manual Z
Manual Z
BEGIN
Cable
SRL
Connector Model
CAL
Connector Model
CAL
Marker
DISPLAY
Limit Menu
Add Limit
Add Max Line
Add Min Line
Add Max Point
Add Min Point
MARKER
Marker
Functions
MARKER
