Chapter 1 1-219
Alphabetical Command Reference
SAVU
SAVU
Syntax
SAVU<ASCI|BINA>;
Description
Front Panel Equivalents
SCAL
Syntax
SCAL<num>; or SCAL?;
Description
Front Panel Equivalents
Command Description Range Query Response
SAVUASCI Selects ASCII format for saving to disk.
Conforms to CITIFile specifications.
N/A N/A
SAVUBINA Selects binary format for saving to disk. N/A N/A
Command Hardkey Softkey
SAVUASCI
SAVUBINA
Command Description Range Query Response
SCAL Sets the trace scale factor.
amplituderange
1
1. For log mag: ± 500 dB. For phase: ± 500 degrees. For Smith chart and Polar: ± 500 units. For linear magnitude:
± 500 units. For SWR: ± 500 units. The scale is always positive, and has minimum values of 0.001dB, 10e−12
degrees, 10e−15 seconds, and 10 picounits.
<num><
L
F
>
Command Hardkey Softkey
SCAL
Save/Recall
Save/Recall
Scale Ref
