Agilent Technologies 8719ET Programmer's Guide

1-236 Chapter1
Alphabetical Command Reference
SMI
SMI
Syntax
SMI<C|MGB|MLIN|MLOG|MRI|MRX>; or SMI<C|MGB|MLIN|MLOG|MRI|MRX>?;
Description
Front Panel Equivalents
Command Description Range Query Response
SMIC Selects Smith chart display format. N/A
<0|1><
L
F
>
SMIMGB Selects G+jB (conductance and
susceptance) marker readout on a Smith
chart.
N/A
<0|1><
L
F
>
SMIMLIN Selects linear magnitude marker readout
on a Smith chart.
N/A
<0|1><
L
F
>
SMIMLOG Selects log magnitude marker readout on
a Smith chart.
N/A
<0|1><
L
F
>
SMIMRI Selects real/imaginary pairs (resistance
and reactance) marker readout on a Smith
chart.
N/A
<0|1><
L
F
>
SMIMRX Selects R + jX marker readout on a Smith
chart.
N/A
<0|1><
L
F
>
Command Hardkey Softkey
SMIC
SMIMGB
SMIMLIN
SMIMLOG
SMIMRI
SMIMRX
Format
SMITH CHART
Marker Fctn
G + jB MKR
Marker Fctn
LIN MKR
Marker Fctn
LOG MKR
Marker Fctn
Re/Im MKR
Marker Fctn
R + jX MKR
