Chapter 3 3-11
GPIB Programming
GPIB Operation
GPIB Operational Capabilities
On the network analyzer's rear panel, next to the GPIB connector, there is a list of GPIB
device subsets as defined by the IEEE 488.2 standard. The analyzer has the following
capabilities:
These codes are completely explained in the IEEE Std 488 documents, published by:
The Institute of Electrical and Electronic Engineers, Inc.
345 East 47th Street
New York, New York 11017
Or, visit their Web site at http://standards.ieee.org
GPIB Status Indicators
When the analyzer is connected to other instruments over the GPIB, the GPIB status
indicators illuminate to display the current status of the analyzer. The GPIB status
indicators are located in the instrument-state function block on the front panel of the
network analyzer.
R = Remote Operation
L = Listen mode
T = Talk mode
S = Service request (SRQ) asserted by the analyzer
SH1
Full-source handshake.
AH1 Full-acceptor handshake.
T6 Basic talker, answers serial poll, unaddresses if MLA is issued. No talk-only mode.
L4 Basic listener, unaddresses if MTA is issued. No listen-only mode.
SR1 Complete service request (SRQ) capabilities.
RL1 Complete remote/local capability including local lockout.
PP0 Does not respond to parallel poll.
DC1 Complete device clear.
DT1 Responds to a Group Execute Trigger (GET) in the hold-trigger mode.
C1,C2,C3 System controller capabilities in system-controller mode.
C10 Pass control capabilities in pass-control mode.
E2 Tri-state drivers.
LE0 No extended listener capabilities.
TE0 No extended talker capabilities.
