Appendix A A-15
Preset Conditions
Preset State
Table A-15 Print Conditions
Preset Conditions Preset Value
Printer Mode Last Active State
Auto-Feed On
Printer Colors:
Ch1/Ch3 Data Magenta
Ch1/Ch3 Mem Green
Ch2/Ch4 Data Blue
Ch2/Ch4 Mem Red
Graticule Cyan
Warning Black
Text Black
Reference Line Black
Table A-16 Format Conditions
Preset Conditions Preset Value
Scale Reference
Position
Reference
Value
Log Magnitude (dB) 10.0 5.0 0.0
Phase (degrees) 90.0 5.0 0.0
Group Delay (ns) 10.0 5.0 0.0
Smith Chart 1.00 N/A 1.0
Polar 1.00 N/A 1.0
Linear Magnitude 0.1 0.0 0.0
Real 0.2 5.0 0.0
Imaginary 0.2 5.0 0.0
SWR 1.00 0.0 1.0
