Making Measurements
Using the Swept List Mode to Test a Device
Set Up the Lower Stopband Parameters
3. To set up the segment for the lower stopband, press
4. To maximize the dynamic range in the stopband (increasing the incident power and
narrowing the IF bandwidth), press
until ON is selected
until ON is selected
Set Up the Passband Parameters
5. To set up the segment for the passband, press
6. To specify a lower power level and a wider IF bandwidth for the passband, press
Set Up the Upper Stopband Parameters
7. To set up the segment for the upper stopband, press
650 M/µ
880 M/µ
51 x1
10 x1
1000 x1
900 M/µ
40 M/µ
.2 M/µ
−10 x1
3700 x1
920 M/µ
1150 M/µ
51 x1
