1-114
Making Measurements
Using Test Sequencing to Test a Device
Using Test Sequencing to Test a Device
Test sequencing allows you to automate repetitive tasks. As you make a measurement, the
analyzer memorizes the keystrokes. Later you can repeat the entire sequence by pressing a
single key.
This section contains the following example sequences:
• “Cascading Multiple Example Sequences”
• "Loop Counter Example Sequence" on page 1-115
• "Generating Files in a Loop Counter Example Sequence" on page 1-116
• "Limit Test Example Sequence" on page 1-118
Cascading Multiple Example Sequences
By cascading test sequences, you can create subprograms for a larger test sequence. You
can also cascade sequences to extend the length of test sequences to greater than 200 lines.
In this example, you are shown two sequences that have been cascaded. You can do this by
having the last command in sequence 1 call sequence position 2, regardless of the sequence
title. Because sequences are identified by position, not title, the call operation will always
go to the sequence loaded into the given position.
1. To create the example multiple sequences, press:
or on ET models:
Seq
Center 134 M/µ
Span
50
M/µ
Seq
Meas
Format
Scale Ref
Seq
To Next Page
