Chapter 2 107
Front-Panel Key Reference
File
Trace Displays all trace (.TRC and .CSV) files
you may wish to rename.
Key Access:
File, Rename, Type
Limits
Displays all limit (.LIM) files you may
wish to rename.
Key Access:
File, Rename, Type
Screen
Displays all screen (.GIF and .WMF)
files you may wish to rename.
Key Access:
File, Rename, Type
Corrections
Displays all corrections (.CBL, .ANT,
.OTH, .AMP) files you may wish to
rename.
Key Access:
File, Rename, Type, More
Measurement Results
Displays all previously saved
measurement results files you may
wish to rename. Measurement results
files are saved in (.CSV) format (for
importing into spreadsheets).
Key Access:
File, Rename, Type, More
Sort
Sort accesses a menu of keys that allow you to view the
files you wish to rename according to a selected file
attribute. The selections include,
By Date, By Name, By
Extension
, By Size, and Order Up Down. Order (UP) allows
you to view files you may wish to rename in ascending
order (for instance, A,B,C).
Order (Down) allows you to
view files you may wish to rename in descending order
(for instance, C,B,A).
Key Access:
File, Rename
Name
Accesses the Alpha Editor and allows you to enter a
filename. The external keyboard can also be used to
enter a filename while the alpha editor is accessed.
Complete your entry by pressing
Return or Enter.
NOTE Only capital letters (A-Z) and digits (0-9) may appear in file names
(8 characters, maximum). Additionally, file names include a 3 character
extension which is automatically set by the instrument.
Key Access:
File, Rename
Dir Up
Allows you to move up one directory level. If at the top
level,
Dir Up moves to the drive level, displaying the
available disk drives.
Key Access:
File, Rename
