Chapter 2 221
Front-Panel Key Reference
Trace/View (Channel Power)
Trace/View (Channel Power)
If Channel Power is selected in the MEASURE menu, Trace/View displays
the following menu for the channel power measurement.
Spectrum Selects the spectral display of the measurement.
Key Access:
Measure, Channel Power, Trace/View
Combined
Selects the measurement to be displayed as a bar graph and spectrum.
Key Access:
Measure, Channel Power, Trace/View
Trace
Accesses menu keys that allow you to set how the trace information is
stored and displayed. Refer to “Trace/View” on page 214 for
Trace menu
key information.
Key Access:
Measure, Channel Power, Trace/View
