126 Chapter 2
Front-Panel Key Reference
Meas Control
Meas Control
If in a measurement, accesses a menu of keys that allow you to pause,
resume, or restart one of the measurements available in the
MEASURE
key menu.
Meas Control also allows you to select between continuous
and single sweeps or measurements.
Press
MEASURE and then select one of the available measurements
(
Channel Power, Occupied BW, ACP, Multi-Carrier Power, Power Stat CCDF,
Harmonic Distortion, Burst Power
, Intermod (TOI), Spurious Emissions, or
Spectrum Emission Mask). Once the desired measurement is selected,
press
Meas Control. Meas Control accesses the following keys:
Restart Performs the same functions as the “Restart” front-panel key. Repeats
your measurement from the beginning. Pressing
Restart while a
measurement is being made will halt the current measurement routine
at the first possible stopping point and repeat the measurement.
Key Access:
Meas Control
Measure
Single Cont
Measure
(Single) allows you to take one measurement sweep and display
the measurement results.
Measure (Cont) allows you to continuously run
a measurement, displaying the results after each measurement sweep.
Key Access:
Meas Control
Pause
Allows you to pause a measurement. Pressing Pause will toggle between
pausing and resuming your measurement. The key label will toggle
between
Pause and Resume. If an averaged measurement was in
progress, the average counter is frozen and the measurement sweeping
is halted.
Key Access:
Meas Control
NOTE The measurements described above are those available in SA mode (see
Mode key). Other measurements are available in other modes if an
optional personality is installed.
