Chapter 2 219
Front-Panel Key Reference
Trace/View (Multi-Carrier Power)
Trace/View (Multi-Carrier Power)
If Multi-Carrier Power (MCP) is selected in the MEASURE menu,
Trace/View displays the following menu for the (MCP) measurement.
Spectrum Selects the spectral display of the measurement.
Key Access:
Measure, Multi-Carrier Power, Trace/View
Combined
Selects the measurement to be displayed as a bar graph and spectrum.
Key Access:
Measure, Multi-Carrier Power, Trace/View
Combined
Rel Abs
Allows you to select relative (dB) or absolute (dBm) levels to be
displayed in the graphic section of the display. Both bar graph and
spectrum views are shown.
Key Access:
Measure, Multi-Carrier Power, Trace/View
Trace
Accesses menu keys that allow you to set how the trace information is
stored and displayed. Refer to “Trace/View” on page 214 for
Trace menu
key information.
Key Access:
Measure, Multi-Carrier Power, Trace/View
