184 Chapter 2
Front-Panel Key Reference
Source
Key Access: Source, More, Normalize
Norm Ref Lvl
Sets the level (in dB) of the normalized reference.
Key Access:
Source, More, Normalize
Norm Ref Posn
Offsets the displayed trace without affecting the
instrument gain or attenuation settings. This allows
the displayed trace to be moved without decreasing
measurement accuracy. The normalized reference
position is indicated with a (>) character on the left side
of the display and a (<) character on the right side of
the display.
Key Access:
Source, More, Normalize
Ref Trace
View BLank
Allows you to view or blank the reference trace on the
display.
Key Access:
Source, More, Normalize
Tracking Peak
Agilent E4402B, E4403B, E4404B, E4405B, E4407B, and E4408B only.
Activates a routine that automatically adjusts fine tracking
adjustments to obtain the peak response of the tracking generator on
the spectrum analyzer display. Tracking Peak is performed in the active
resolution bandwidth.
Key Access:
Source, More
Man Track Adj
Agilent E4402B, E4403B, E4404B, E4405B, E4407B, and E4408B only.
Allows you to adjust the frequency of the tracking generator oscillator
manually using the step keys, knob, or numeric keypad. The tracking
adjust is tuned to maximize the amplitude of the trace.
Key Access:
Source, More
NOTE When Source is On, resolution bandwidths less than 1 kHz are not
available.
NOTE When the resolution bandwidth is less than 1 kHz, Source may not be
turned on.
