Agilent Technologies E4402B - AMPLITUDE Y Scale Function - Editing and Deleting Correction Data

Chapter 2 61
Front-Panel Key Reference
AMPLITUDE Y Scale
you are sure, press key again to
delete will appear on the display.
Pressing
Delete Point again will delete
the point and adjust all of the point
numbers as appropriate.
Key Access:
AMPLITUDE Y Scale, More,
Corrections
, Antenna, Edit
Delete Correction
Allows you to clear all data from the
selected amplitude-correction set. The
prompt If you are sure, press key
again to delete will appear on the
display. Pressing
Delete again will
delete the correction set.
Key Access:
AMPLITUDE Y Scale, More,
Corrections, Antenna
Cable
Allows you to correct for cable loss, but may be used for
any kind of correction.
Key Access:
AMPLITUDE / Y Scale, More, Corrections
Correction On Off
Turns the amplitude correction
function on or off for the selected set.
The corrections state must be set to On
for the correction to be applied.
Key Access:
AMPLITUDE / Y Scale, More,
Corrections, Cable
NOTE Antenna, Cable, and Other correction factors are generally entered as
positive values. This indicates a loss in the external device. User
correction factors are typically entered as negative values which
indicate a gain in the external device.
Edit Accesses menu keys that allow you to
create and edit an amplitude-correction
factor set. It puts the analyzer into a
split-screen mode where the correction
data is displayed in a table under the
trace data. Pressing
ESC while in this
menu will exit the menu and remove
the table from the screen. New points
will be applied only after the editor is
closed. The Tab keys are very useful for
navigation between rows in the
corrections table.
Key Access:
AMPLITUDE Y Scale, More,
Corrections
, Cable
