Agilent Technologies E4402B - Display Function - Fixed;Relative Limits and Title Settings

92 Chapter 2
Front-Panel Key Reference
Display
Limits Fixed Rel Allows you to choose fixed or relative limit lines. The fixed (Fixed) type
uses the current limit line as a reference with fixed frequency and
amplitude values. The relative (
Rel) setting causes the current limit
line value to be relative to the displayed center frequency and reference
level amplitude values. When limit lines are specified with time, rather
than frequency, the
Rel setting only affects the amplitude values. The
current amplitude values will be relative to the displayed reference
level amplitude, but the time values will always start at the left edge of
the graticule.
As an example, assume you have a frequency limit line. If the limit line
is specified as fixed, entering a limit line segment with a frequency
coordinate of 300 MHz displays the limit line segment at 300 MHz. If
the same limit line table is specified as relative, it is displayed relative
to the analyzer center frequency and reference level. If the center
frequency is at 1.0 GHz, a relative limit line segment with a frequency
coordinate of 300 MHz will display the limit line segment at 1.3 GHz. If
the amplitude component of the relative limit line segment is –10 dB,
then
−
10 dB is added to the reference level value to obtain the
amplitude of the given segment (reference level offset included).
A limit line entered as fixed may be changed to relative, and one
entered as relative may be changed to fixed. When changing between
fixed and relative limit lines, the frequency and amplitude values in the
limit line table change so that the limit line remains in the same
position for the current frequency and amplitude settings of the
analyzer. If a time and amplitude limit line is used, the amplitude
values change but the time values remain the same.
Key Access:
Display, Limits
Delete
All Limits
Allows you to purge data from the limit-line tables. Pressing Delete
Limits
after the prompt, If you are sure, press key again to
delete, will delete the limits.
Key Access:
Display, Limits
Title
Accesses the following Title menu keys which allows you to change or
clear a title on your display.
Key Access:
Display
Change Title Allows you to write a title across the top of the display.
The marker readout may interfere with the last
characters. The markers can be turned off by pressing
Marker, More, Marker All Off. Pressing Change Title
accesses the Alpha Editor Menus that contain available
characters and symbols.
NOTE Pressing ESC before exiting the Alpha Editor menus will retain the
previous title.
