Agilent MOI for DisplayPort Cable & Connector Compliance Tests
19
Intra-pair Skew Upper Limit for High Bit Rate Cable Assembly
delta time <= 50 ps, then Pass. Otherwise Fail.
delta time <= 10 ps, then Pass. Otherwise Fail.
delta time <= 35 ps, then Pass. Otherwise Fail.
Intra-pair Skew Upper Limit for Reduced Bit Rate Cable Assembly
delta time <= 250 ps, then Pass. Otherwise Fail.
5.5.3. Insertion Loss
5.5.3.1. Load Limit file
Refer to 5.5.1.1.
Table 5-4 Insertion Loss Limit Line File for Trace 3 in Channel 2
DP_HBR_InsertionLoss_Cable.CSV
DP_HBR_InsertionLoss_Adapter.CSV
DP_HBR_InsertionLoss_ExtCable.CSV
5.5.3.2. Measurement
1. Connect the test fixture to the test cables according to the Table 5-3. Unused test ports
should be terminated.
2. Connect Display Port cable to the test fixture.
3. Press Channel Next key to select Channel 1.
4. Press Channel Max key to enlarge Channel 1.
5. Press Trigger > Single for frequency domain measurement.
To Next Page
