Agilent MOI for DisplayPort Cable & Connector Compliance Tests
35
6.2.4. Inter-pair Skew Measurements (Normative)
6.2.4.1. Measurement Setup
1. Select Trace 3.
2. Open Parameters tab.
3. Select Rise Time to 10-90 % and input value to 50 psec.
4. Click the box below the left knob under Horizontal. Then Entry dialog box appear.
5. Input horizontal scale to 5 ns/div.
6. Click the box below the right knob under Horizontal. Then Entry dialog box appear.
7. Input horizontal position to 0 s.
8. Click the box below the left knob under Vertical. Then Entry dialog box appear.
9. Input vertical scale to 100 mV/div.
10. Click the below the right knob under vertical. Then Entry dialog box appear.
11. Input vertical scale to 200 mV.
12. Press Marker Search > Target > Target Value and enter “60 mUnits”.
13. Click Return.
14. Click Tracking to turn it on.
15. Select Trace 4.
16. Click Data Mem and select OFF.
17. Repeat step15 to step16 for Trace 7 and Trace 8.
6.3. Manual Setup for Frequency Domain Measurement
6.3.1. Channel and Trace Settings
1. Press Display.
2. Click Allocate Channels > .
3. Press Channel Next.
4. Click Num of Traces > 6.
5. Click Allocate Traces > .
