Agilent MOI for DisplayPort Cable & Connector Compliance Tests
20
5.5.3.3. Data Analysis
Read Pass/Fail signs on Trace 3. (item 1 in Figure 5-4).
Figure 5-4: Frequency Domain Measurement Example
5.5.4. Return Loss
5.5.4.1. Load Limit File
Refer to 5.5.1.1.
Table 5-5 Return Loss Limit Line File for Trace 2 and Trace 6 in Channel 2
Bit Rate
Cable Category
Connector Type
File Name
HBR
All
All
DP_HBR_ReturnLoss.CSV
RBR
All
All
DP_RBR_ReturnLoss.CSV
5.5.4.2. Cable Connection
Refer to 5.5.1.2.
