Agilent Technologies E5071C Compliance Tests

Agilent MOI for DisplayPort Cable & Connector Compliance Tests
8
Figure 5-2: Cable connection
The cables and fixtures should be connected to the instrument as shown in the figure above.
Table 5-1 shows the cable connection for each measurement item. The measurement items
of the same cable connection can be done simultaneously.
Table 5-1 Cable and Fixture Connection
ENA Port Number
Port1
Port2
Port3
Port4
Fixture PIN Number
Bulk Cable and Connector Impedance
Intra-pair Skew
Insertion Loss
Return Loss
A ML0+
A ML0-
B ML0+
B ML0-
A ML1+
A ML1-
B ML1+
B ML1-
A ML2+
A ML2-
B ML2+
B ML2-
A ML3+
A ML3-
B ML3+
B ML3-
A AUX+
A AUX-
B AUX+
B AUX-
Inter-pair Skew
A ML0+
A ML1+
A ML2+
A ML0-
A ML1-
A ML2-
B ML0+
B ML1+
B ML2+
B ML0-
B ML1-
B ML2-
