Appendix B 141
SCPI Command Reference
List by front panel key
List by front panel key
Table B-2 shows the fault location SCPI commands that correspond to the front panel keys
(in alphabetical order).
Table B-2 Front panel key tree vs. fault location SCPI commands correspondence table
Key (operation) Corresponding GPIB command
[Analysis] Fault
Location
Cable Loss :CALC{1-4}:TRAN:DIST:CLOS on page 114
:CALC{1-4}:TRAN:TIME:CLOS on page 129
Center :CALC{1-4}:TRAN:DIST:CENT on page 113
:CALC{1-4}:TRAN:TIME:CENT on page 128
Fault Location :CALC{1-4}:TRAN:DIST:STAT on page 121
:CALC{1-4}:TRAN:TIME:STAT on page 136
Reflection Type :CALC{1-4}:TRAN:DIST:REFL:TYPE on page 118
:CALC{1-4}:TRAN:TIME:REFL:TYPE on page 133
Set Freq Low Pass :CALC{1-4}:TRAN:DIST:LPFR on page 117
:CALC{1-4}:TRAN:TIME:LPFR on page 132
Span :CALC{1-4}:TRAN:DIST:SPAN on page 119
:CALC{1-4}:TRAN:TIME:SPAN on page 134
Start :CALC{1-4}:TRAN:DIST:STAR on page 120
:CALC{1-4}:TRAN:TIME:STAR on page 135
Stop :CALC{1-4}:TRAN:DIST:STOP on page 124
:CALC{1-4}:TRAN:TIME:STOP on page 139
Type :CALC{1-4}:TRAN:DIST on page 112
:CALC{1-4}:TRAN:DIST:STIM on page 123
:CALC{1-4}:TRAN:TIME on page 127
:CALC{1-4}:TRAN:TIME:STIM on page 138
Unit :CALC{1-4}:TRAN:DIST:UNIT on page 125
:CALC{1-4}:TRAN:METH on page 126
Window Impulse Width :CALC{1-4}:TRAN:DIST:IMP:WIDT on page 115
:CALC{1-4}:TRAN:TIME:IMP:WIDT on page 130
Kaiser Beta :CALC{1-4}:TRAN:DIST:KBES on page 116
:CALC{1-4}:TRAN:TIME:KBES on page 131
Maximum
Minimum
Normal
Step Rise :CALC{1-4}:TRAN:DIST:STEP:RTIM on page 122
:CALC{1-4}:TRAN:TIME:STEP:RTIM on page 137
