11 2 Appendix B
SCPI Command Reference
:CALC{1-4}:TRAN:DIST
Fault Location Commands
This section describes the commands specific to the fault location function of the
E5061A/E5062A.
:CALC{1-4}:TRAN:DIST
Syntax :CALCulate{[1]|2|3|4}[:SELected]:TRANsform:DISTance[:TYPE] {BPASs|LPASs}
:CALCulate{[1]|2|3|4}[:SELected]:TRANsform:DISTance[:TYPE]?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), selects the
transformation type used for the transformation function of the fault location function.
Parameters
Query response {BPAS|LPAS}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:TRAN:DIST LPAS"
20 OUTPUT 717;":CALC1:TRAN:DIST?"
30 ENTER 717;A$
Related commands :CALC{1-4}:TRAN:TIME on page 127
:CALC{1-4}:TRAN:DIST:STAT on page 121
:CALC{1-4}:TRAN:DIST:STIM on page 123
Equivalent key [Analysis] - Fault Location - Type - Bandpass|Lowpass Step|Lowpass Imp.
NOTE When performing this operation from the front panel, you select the stimulus type at the
same time.
Description
BPASs (preset value)
Specifies the band-pass
*1
.
LPASs
Specifies the low-pass
*2
.
*1.You do not need to select the stimulus type. Impulse is selected automatically.
*2.You need to select the stimulus type (impulse or step) with the
:CALC{1-4}:TRAN:DIST:STIM command.
