140 Appendix B
SCPI Command Reference
List by function
Fault Location Command list
List by function
Table B-1 shows the fault location SCPI command list by function.
Table B-1 Fault location SCPI command list by function
Function Setting/execution item Command
Fault Location Transform ON/OFF :CALC{1-4}:TRAN:DIST:STAT on page 121
:CALC{1-4}:TRAN:TIME:STAT on page 136
Transformation type :CALC{1-4}:TRAN:DIST on page 112
:CALC{1-4}:TRAN:TIME on page 127
Stimulus type :CALC{1-4}:TRAN:DIST:STIM on page 123
:CALC{1-4}:TRAN:TIME:STIM on page 138
Changing the frequency range to
match with the low-pass type
:CALC{1-4}:TRAN:DIST:LPFR on page 117
:CALC{1-4}:TRAN:TIME:LPFR on page 132
Reflection type :CALC{1-4}:TRAN:DIST:REFL:TYPE on page 118
:CALC{1-4}:TRAN:TIME:REFL:TYPE on page 133
Cable Loss :CALC{1-4}:TRAN:DIST:CLOS on page 114
:CALC{1-4}:TRAN:TIME:CLOS on page 129
Method, Distance unit :CALC{1-4}:TRAN:METH on page 126
:CALC{1-4}:TRAN:DIST:UNIT on page 125
Window setup β :CALC{1-4}:TRAN:DIST:KBES on page 116
:CALC{1-4}:TRAN:TIME:KBES on page 131
Impulse width :CALC{1-4}:TRAN:DIST:IMP:WIDT on page 115
:CALC{1-4}:TRAN:TIME:IMP:WIDT on page 130
Rise time of step
signal
:CALC{1-4}:TRAN:DIST:STEP:RTIM on page 122
:CALC{1-4}:TRAN:TIME:STEP:RTIM on page 137
Display range
after time
domain
transformation
Start value :CALC{1-4}:TRAN:DIST:STAR on page 120
:CALC{1-4}:TRAN:TIME:STAR on page 135
Stop value :CALC{1-4}:TRAN:DIST:STOP on page 124
:CALC{1-4}:TRAN:TIME:STOP on page 139
Center value :CALC{1-4}:TRAN:DIST:CENT on page 113
:CALC{1-4}:TRAN:TIME:CENT on page 128
Span value :CALC{1-4}:TRAN:DIST:SPAN on page 119
:CALC{1-4}:TRAN:TIME:SPAN on page 134
